Description
Features:
Versatile Charging: Supports a broad range of EVs, from cars to trucks, buses, speedboats, and off-road machinery.
Plug & Play: Integrated AC supply plug allows for quick and easy setup—just plug into the mains and start charging.
Mobile and Stationary Use: Can be easily moved for temporary charging needs or bolted down for semi-stationary use.
Dual Charging Points: Offers either 40 kW at a single charging point or 20 kW across two points simultaneously.
Remote Access: Nearly all Kempower ChargEye features for seamless OCPP server integration and fleet testing.
User-Friendly Interface: Equipped with a touch screen and RFID reader for easy monitoring and management of charging sessions.
Specifications
Weight: 160–180kg
Dimensions (H,W,D): 1216mm, 638mm, 670mm
Product Type: DC Portable Charger
Colour: Grey/Black
Charging Mode: Type 2 and CCS2
Cable Length: 5m
Connector Type: Type 2 Plug and CCS2
Rated Power: 40 kW (with 2 outputs: Dynamic 40 kW one output or 20 kW per output) at 400 VDC
Rated Current: 2 x 50 A, 1 x 100 A
Rated Voltage: 500VDC
Nominal Charging Cable Current: 2 x 150 A
Rated Frequency: 50Hz / 60Hz
Connectivity: WiFi, Cellular/GPS, Ethernet
Communication protocols: OCPP 1.6J/2.0.1
Operating Temperature: -30°C to 50°C
Operating Altitude: 2000m
Storage Temperature: -40°C to 60°C
IP and IK rating: IP54, IK10
Safety Standards: IEC 61851-1 IEC 61851-23 IEC 61851-21-2
