Description
Specifications:
- Connectors: CCS-2 x 2, CHAdeMO (Optional)
- DC Power Output: 60kW or 120kW (150V-1000V DC)
- 200Amp Max per Connector
- Supply Input: 3-Phase 400V ± 15%
- Supply frequency: 50-60 Hz
- IP55
- Warranty: 2 Years
- Cable Length: 7m (Retractable pulley)
- Forced Air Cooling
- RFID & Mobile App Authentication
- Credit Card Terminal as Standard
- Efficiency: >=94%
- Power Factor: >=0.99
- Display: 21.5” CTP Touchscreen with Ad Space
- Operating Temperature: -30℃ to 55℃
- Network Connection: Ethernet, 4G, Modbus (TCP/IP)
- OCPP Compatibility: OCPP1.6J, Upgradable to OCPP2.0.1
- Weight: 300kg (60kW) / 345kg (120kW)
- Dimensions: 1900(H) x 1052(W) x 470(D) mm
- Certifications: CE, IEC/EN 61851-1, IEC/EN 61851-23, IEC/EN 61851-21-2, RCM
- Electrical Protection: Overcurrent, Short Circuit, Over/Under Voltage, Ground Fault, Lightning Surge, Over Temperature
Keep this in mind when installing:
For your safety, the installation must only be carried out by a licensed and qualified electrician familiar with Australian industry standards and is fully responsible for the installation
Please note charging speed is also dependent on the vehicle- The unit delivers 250Amp maximum x Voltage of the vehicle. If the vehicle can charge at a voltage above 600V it will be 150kW. If 400V it will charge at 100kW.
