Description
Input & Output
- Input voltage/Output voltage – AC 230V
- Adjustable output – 6A – 32A – Via Bluetooth APP
- Manual override -plug and charge via side button
- Input frequency – 50Hz
- Max. output power – 7.4KW(1 Phase)
- Max. output current – 32Amp
- Charging interface type – IEC 62196-2, SAE J1772
Protection
- Over voltage protection
- Under voltage protection
- Over load protection
- Short circuit protection
- Earth leakage protection
- Over-temp protection
- Lightning protection
Function and Accessory
- LCD – 3.5 inch
- RCD – Type A + 6mA DC
- LED Indicator light
Working environment
- Protection degree – IP66
- Environment temperature – -40 – 75 Degrees Celsius
- Relative humidity – 0-95%
- Cooling – Natural Air Cooling
- Standby power consumption – <8W
Mechanical
- Dimension (W/H/D) – 295/195/65mm
- Weight – 6 kg
Mounting Accessories
- Wall-mounting bracket
- Ground-mounting pole – Optional
Certificate
- CE, TUV, FCC, CSA, RoHS, RCM mark
