Description
Features
Run-over Proof: Rugged design that withstands the toughest conditions.
Safe and Compliant: IP67 and IK10 ratings ensure maximum safety. RCD protection against DC and AC fault currents eliminates the need for expensive building installations.
Global Compatibility: Can charge electric vehicles from virtually any conventional household or industrial socket worldwide.
Specifications
Weight: 1.0kg excluding cables, 3.2kg with cables and plugs
Dimensions: Length 265mm, Diameter 70mm
Product Type: Portable Charger
Colour: Metallic anthracite, black rubber caps and cables
Rated Power: 1.4 – 22kW depending on input current
Rated Current: Up to 32A maximum
Rated Voltage: 230V, Single Phase or 400V, Three Phase
Operating Temperature: -25°C to +45°C
Storage Temperature: -30°C to +60°C
Standards: IEC 62752, 62196, 61851 Mode 2, 61851 Mode 3 (with type 2/type 3c adapter plug), EMC, RoHS
